Constant Current 3528 LED Strip

Features
(-)

Light source:60pcs/m SMD3528

10-50M Constant Current LED Strips

Material:suoerior and heat-resistant 8mm PCB(1:1)

Input voltage:DC24V

RA>80,RA>90

IP rate:IP20,IP65,IP67

Lifespan:30,000hours

Easy installation,cuttable and joinable

Accessories complete.

Download
(+)

Color                       CCT                   Lumen/m       Max.Power/m       LED Type            LED Qty/m       Input Voltage    IP

                            2200-2400K             336LM

                            2400-2600K             345LM

Warm white           2600-2800K             355LM

                            2800-3000K             365LM

                            3000-3200K             365LM             4.8            3528 SMD LED           60PCS               DC24V        20

Natural white         4000-4500K             384LM

Cool white             5000-5500K             374LM

                            6000-6500K             374LM




Current(Amps/m)   Min Cuttable Length(mm)   Beam Angle   Operating Temperature   Storage Temperature   Estimated Life
0.48                                100                            120°             -25°C~+45°C                  -30°C~+80°C            30,000hrs
