Constant Current 2835 LED Strips

Features
(-)

Light source:6pcs/m SMD 2835

10-50Constant Current LED Strips

Material: superior and heat-resistant 10mm PCB(1:2)

Input voltage:DC 24V

RA>80,RA>90,RA>95

IP rate:IP20,IP65,IP67

Lifespan:30,000 hours

Easy installation,cuttable and joinable,

Accessories complete.

Download
(+)

Color                       CCT              Lumen/m         Max.Power/m         LED Type            LED Qty/m       Input Voltage       IP


                           2200-2400k           870LM

                           2400-2600k           890LM

Warm white          2600-2800k           910LM

                           2800-3000k           930LM            11.52            2835 SMD LED              60PCS              DC24V           20

                           3000-3200k           930LM

Natural white        4000-4500k           970LM

Cool white            5000-5500k           950LM

                           6000-6500k           950LM




Current(Amps/m)     Min Cuttable Length(mm)     Beam Angle     Opreating Temperature       Storage Temperature    Eatimated Life
0.48                                   100                                120°               -25°C~+45°C                    -30°C~+80°C              30,000 hrs
